CK4220 CAB

CK4220 CAB

Request Details Find Out More

Description

The DK Series comes in 48 hp and 58 hp versions which are renowned as the most valuable compact tractors on the market. With its innovative design, smooth transmission and improved performance to suit a variety of farming needs and property sizes, the DK Series offers both power and versatility.

Specifications

  • ENGINE
    add remove
    • Engine
      Daedong 3B183LWM-E
    • Cylinders
      Liquid Cooled 3 Cylinder Diesel
    • Horsepower RPM
      42hp @ 2600 rpm
    • Displacement (ci)
      1826cc
  • TRANSMISSION
    add remove
    • Transmission
      12x12 Synchro Shuttle or 3 Range Hydrostatic Drive
    • Maximum Forward Speed (kph)
      23.56
    • Other Transmission
      4 Wheel Drive
  • HYDRAULIC SYSTEM
    add remove
    • Hydraulic System
      4 Hydraulic Remotes (2 Rear, 2 Front w/Joystick)
    • Rear 3-Point Hitch Category
      Category 1
    • Other Hydraulic System
      740kg Max Rear Lift Capacity 600mm Behind Lift
  • TECHNICAL SPECIFICATIONS
    add remove
    • Length (mm)
      3070
    • Width (mm)
      1400
    • Height (mm)
      2330
    • Wheelbase (mm)
      1670
    • Ground Clearance (mm)
      340
    • Dry Weight (kg)
      1,500
    • Fuel Capacity (l)
      34 Litre
  • WHEELS & TIRES
    add remove
    • Front Tire (Full Spec)
      Industrial: 25/8.5x14, Turf: 27x18.5-15
    • Rear Tire (Full Spec)
      Industrial: 15/19.5, Turf: 41x14.00-12.4
  • BRAKES
    add remove
    • Brakes
      Wet Disc Brakes
  • HVAC
    add remove
    • Air Conditioning
      Yes
  • Color options
    add remove
    • Orange
